Autoclave Sterilizers for Hospital & Laboratory

We are ISO and CE Certified leading, Autoclaves manufacturing company in India that meet stringent sterilization requirements anywhere in hospitals and pharmaceutical laboratories etc. From general sterilization applications to special sterilization needs, these autoclave machines deliver reliable results while offering simple operation and almost no maintenance features.

Our company is committed to produce such autoclave sterilizer Machines that meet or exceed industry standards required for effective sterilization. Our autoclaves can be successfully utilized in many industry sectors including laboratory, healthcare, clinics and hospitals, pharmaceutical research, tissue culture and agriculture, etc. In addition to supply pre-engineered standard models, we also manufacture autoclaves with customer provided specifications with a choice of optional accessories that may be used to add flexibility in operation.



#1 Autoclaves Manufacturers in India

Bionics Scientific Technologies is a Delhi based ISO and CE certified leading autoclave manufacturers in India. We are leading suppliers Machines in Delhi NCR, PAN India and Overseas. We manufacture autoclave sterilizers that meet stringent sterilization requirements anywhere in hospitals and pharmaceutical laboratories etc. From general sterilization applications to special sterilization needs, these autoclave machines deliver reliable results while offering simple operation with almost no maintenance cost

Our Sterilization machines are highly demanded in many industry sectors including laboratory, healthcare, clinics and hospitals, pharmaceutical research, tissue culture and agriculture, etc . We also manufacture customized autoclave machines with a choice of optional accessories that overall increases the effectiveness of the equipment. We manufacture different kinds of autoclave Machines like Vertical autoclave (top loading), front loading small, Double door autoclave, Horizontal autoclave, Rotary Sterilizer, Dental, Plasma Sterilizer to name a few.

Salient Features & Benefits of Autoclave

  • • Full and semi-automatic models
  • • Lid, flanges, Inner and out camber cover made of Stainless steel
  • • Double, Triple, SS GMP Walled Construction
  • • Operating Pleasure Range 15 - 30 psi
  • • Digital and Analog pressure display
  • • Temperature Range 121 °C to 134°C
  • • High quality Door GasKet
  • • Safety Feature: Pressure release valve, High Temperature cut-off
  • • Ergonomic ASME Standard Design
  • • Sterilization Time : 15 to 20 minutes
  • • CE & ISO, IQ / OQ / DQ / PQ Certified
  • • Requires minimum maintenance
  • • PAN India Supply
  • • Premium quality products with manufacturer’s warranty
  • • 35+ Years Industry experience
  • • Affordable Pricing
  • • Strong logistic support in Delhi NCR & India
  • • Pre-sale and post-sale support services in all India & Overseas
  • • Satisfied clients base ranging from DRDO, UNIECF to ISRO

What is an Autoclave Machine?

An autoclave is a pressure chamber (apparatus), also referred to as a steam sterilizer or Sterilization machine used for healthcare or industrial applications to sterilize equipment at 121 °C to 134°C, around 15 to 20 minutes . Autoclave use steam under pressure to kill the harmful virus, spores, bacteria, and fungi of the equipment’s that are stored inside the pressure chamber.

What is Working Principal of an Autoclave / steam sterilizers?

There are two types of steam sterilizers, gravity displacement and pre-vacuum sterilizer. Some autoclave used both methods to sterilize the equipment. The items or materials which need to sterilize placed inside an autoclave machine and the lid is sealed. After this, most of air is removed from vessel via two ways. The Gravity displacement unit pumps steam into the vessel for removing air and for creating a vacuum. A pre-vacuum design removes the air via a vacuum pump. Once air removal process takes place, pumping of steam at a high temperature takes place into the chamber. This eventually leads to increase in temperature. Once, the temperature reaches to the pre-defined levels, the steam keeps entering into the vessel and the desired temperature is maintained.

What is Different Phases of Sterilization Cycle?

The sterilization process takes into 3 cycles which are as follows:

  • 1.Purge Phases: As steam flows, air starts displacing. The pressure and temperature increase slightly to ensure a continuous flow purge.
  • 2.Exposure Phase: Also known as the sterilization phase, during this phase, the control system of the autoclave machine is programmed so that the exhaust valve closed when the pressure and the interior temperature reach the pre-defined point. This program helps in maintaining the ideal temperature within the closed chamber till a pre-defined time.
  • 3.Exhaust Phase: In the exhaust phase, the release of pressure takes place from the closed chamber via an exhaust valve. Once pressure is released, the interior of the chamber restores the ambient temperature

What is Ideal Temperature Rage & Time for Autoclave Sterilization?

The autoclave sterilization process takes place at 121°C (250°F) but sometimes, materials need to sterilize at higher temperatures, say up to 134°C. The sterilization process of medical equipment takes place when they are placed inside the autoclave for 3 to 4 minutes and for 15-20 minutes. The temperature and time limit may be increased based on the type of material

What are Different Components of Steam Sterilizer Machine ?

A standard autoclave used in a laboratory comprises the following components:

  • 1.Vessel:It is the main body of the autoclave and encompasses an outer jacket and an inner chamber. In hospitals and laboratories, autoclaves have “jacketed chambers”. These chambers are filled with steam for completing the sterilization cycle quickly. The inner chambers feature 316 L stainless steel or nickel-clad whereas outer jackets support 304 L, 316 L or even carbon steel. The size of vessels used in hospitals and laboratory purposes may vary from 100 to 3,000 L.
  • 2.Control System: :All autoclaves feature a control system either modern or simple one. The simple control system supports a “push button” system along with a microprocessor whereas the modern control system equips with a programmable logic controller along with a touch screen.
  • 3. Thermostatic Trap: A thermostatic trap is a device that helps water and air to escape from the internal chamber. It is also known as a steam trap and is considered an important component of a well-designed autoclave
  • 4. Safety Valve: All autoclaves feature scores of safety features and the safety valve is one amongst many. It is a fail-safe device present in all autoclaves so that autoclave performs efficiently even under elevated pressure
  • 5. Waste- Water Cooling Mechanism: Some autoclaves have an in-built mechanism of waste-water cooling that cools air and steam before they enter into the drain piping.
